TracoPower TXM 100-105 PSU 5 V DC 20 A 100 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 88.23 / piece)
€ 88.23
plus VAT.
Only 3 Piece(s) available
Highlights & Details
AC/DC power supply, TXM series
- Output 5 V DC / 20 A
- Power 100 W
- Screw terminal
Technical specifications
- Product type
PSU
- Input voltage (max.)
264 V AC
- Max. output current
20 A
- Output current (max.) - rounded
20 A
- Min. input voltage
90 V AC
- Dim
(L x W x H) 37.6 x 98.3 x 129.0 mm
- Output voltage (max.)
5 V DC
- Connection
Screw terminal
100 W
- No. of outputs
1 x
- Type
closed
- Operating temperature (max.)
60 °C
- Max. operating temperature (derating)
40 °C
- Min. operating temperature (derating)
-20 °C
- Weight
455 g
- Width
98.3 mm
- Height
129.0 mm
- Length
37.6 mm
- Type
TXM 100-105
- Output current (min.)
0 A
- Output voltage (min.)
5 V DC
