Transfer module TBY-ADV151-PS-L-2KB-Z Weidmüller Content: 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Transfer module
Total no. of pins
50
Connection
Plug
Mounting type
DIN rail TH35
Technical specifications
- Packaging type
Piece
- Product type
Transfer module
- Total no. of pins
50
- Connection
Plug
- Mounting type
DIN rail TH35
24 - 14
- Stripping length (max.)
7.5 mm
- Dim
(L x W x H) 85 x 190 x 109 mm
- Connector (field)
Spring-loaded connector
- Connector (control)
Jack connector
- Operating current
2 A
- Content
1 pc(s)
- Number of pins
50
- Width
190 mm
- Height
109 mm
- Length
85 mm
- RoHS-compliant
Yes
- Series
TBY
- Max. temperature
+70 °C
- Min. temperature
-25 °C
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
2.5 mm²
- Cross section (flexible) (min.)
0.2 mm²
- Cross section (inflexible) (min.)
0.2 mm²
- Features
TS 35 socket
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2542631 Transfer module TBY-ADV151-PS-L-2KB-Z Weidmüller Content: 1 pc(s)
