TRU COMPONENTS 1577410 LED wired Yellow Circular 10 mm 8500 mcd 25 ° 20 mA
EAN:
Part number:
Item no:
Product type
LED wired
Forward current I(F)
20 mA
Casing
10 mm
Type
Radial lead
Light intensity I(V)
8500 mcd
Datasheet (PDF)
Number
Total (€ 0.12 / piece)
€ 0.52
-77 %
€ 0.12
plus VAT.
14-day return policy included
Technical specifications
- Product type
LED wired
- Factory colour
Yellow
- Forward current I(F)
20 mA
- Operating voltage
2.3 V
- Casing
10 mm
- Type
Radial lead
- Light intensity I(V)
8500 mcd
- Wavelength
588 nm
- Radiation angle
25°
- Type (LEDs)
Water clear
- LED features
LED 10 mm
- Technology
AlGaInP
- Lens type
Circular
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1577410 TRU COMPONENTS 1577410 LED wired Yellow Circular 10 mm 8500 mcd 25 ° 20 mA
User & Safety Instructions
User & Safety Instructions 1577410 TRU COMPONENTS 1577410 LED wired Yellow Circular 10 mm 8500 mcd 25 ° 20 mA
Description
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
