TRU COMPONENTS 1577512 LED wired Yellow Circular 10 mm 1750 mcd 50 ° 20 mA
EAN:
Part number:
Item no:
Product type
LED wired
Forward current I(F)
20 mA
Casing
10 mm
Type
Radial lead
Light intensity I(V)
1750 mcd
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
10
-
€ 0.32
30
9% = € 0.03
€ 0.29
50
12% = € 0.04
€ 0.28
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 10
Total (€ 0.32 / piece)
€ 0.52
-38 %
€ 3.20
plus VAT.
14-day return policy included
Technical specifications
- Product type
LED wired
- Factory colour
Yellow
- Forward current I(F)
20 mA
- Operating voltage
2.3 V
- Casing
10 mm
- Type
Radial lead
- Light intensity I(V)
1750 mcd
- Wavelength
588 nm
- Radiation angle
50°
- Type (LEDs)
Diffused
- LED features
LED 10 mm
- Technology
AlGaInP
- Lens type
Circular
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1577512 TRU COMPONENTS 1577512 LED wired Yellow Circular 10 mm 1750 mcd 50 ° 20 mA
User & Safety Instructions
User & Safety Instructions 1577512 TRU COMPONENTS 1577512 LED wired Yellow Circular 10 mm 1750 mcd 50 ° 20 mA
Description
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
