Turck Magnetic field detector Magnetic M8 T groove PNP BIM-UNT-AP7X-0,3-PSG3S
EAN:
Part number:
Item no:
Product type
Magnetic field detector
Max. operating voltage
30 V
Outputs
PNP
Model
Magnetic
Connector
Plug
Datasheet (PDF)
Technical specifications
- Product type
Magnetic field detector
- Type
BIM-UNT-AP7X-0,3-PSG3S
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Outputs
PNP
- Cable length
0.3 m
- Model
Magnetic
- Connector
Plug
- Installation type
T groove
- Size
M8
- Enclosure material
Plastic
- Contact type
1 maker
IP68
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- Length
28 mm
- Width
5 mm
- Height
6 mm
- (Ø)
8 mm
- Dim
(Ø x H) 8 mm x 6 mm
DC
Plastic
-25-70 °C
Cable with connector
PNP
Cuboid
FALSE
IP68
Magnet
10-30 V
5 mm
6 mm
28 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2832108 Turck Magnetic field detector Magnetic M8 T groove PNP BIM-UNT-AP7X-0,3-PSG3S
User & Safety Instructions
User & Safety Instructions 2832108 Turck Magnetic field detector Magnetic M8 T groove PNP BIM-UNT-AP7X-0,3-PSG3S
