Ubiquiti Networks POE-48-24W PoE injector 1000 MBit/s Passive
EAN:
Part number:
Item no:
Datasheet (PDF)
UbiQuiti Networks POE-48-24W PoE Adapter
Technical specifications
- Output power 48 V DC (at) 0.5 A.
- Input power 90-260 VAC (at) 47-63 Hz
- Input current 0.3 A (at) 120 V AC, 0.2 A (at) 230 V AC
- Efficiency: 70+%
- Output ripple: 1% max.
- Switch frequency 200 kHz
- Input control: +/- 0.5%
- Load control: +/- 1%
- Operating temperature: -10°C to + 60°C.
- Storage temperature: -20°C to +85°C.
- Operating humidity: 5 - 90% non-condensing
- Product type
PoE injector
- PoE
Passive
- LAN data transfer rate
1000 MBit/s
- Width
55 mm
- Height
33 mm
- Length
85 mm
- Depth
8.5 cm
- Factory colour
Multicolour
- Weight
300.00
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1876766 Ubiquiti Networks POE-48-24W PoE injector 1000 MBit/s Passive
User & Safety Instructions
User & Safety Instructions 1876766 Ubiquiti Networks POE-48-24W PoE injector 1000 MBit/s Passive
Description
Ubiquiti Networks - Passive Gigabit PoE injector 48 V, 24 W.
Designed by Ubiquiti for carrier installations. Ideal for use with Rocket-TI, UAP-Pro and MikroTik RB800.
This text is machine translated.
Designed by Ubiquiti for carrier installations. Ideal for use with Rocket-TI, UAP-Pro and MikroTik RB800.
