Ubiquiti Networks POE-50-60W PoE injector 10 / 100 / 1000 MBit/s Passive
EAN:
Part number:
Item no:
Datasheet (PDF)
UbiQuiti Networks POE-50-60W Gigabit Ethernet 50V PoE Adapter
Technical specifications
- Output voltage 50 V DC (at) 1.2 A.
- Input voltage 90-260 V AC (at) 47-63 Hz
- Input current 0.3 A (at) 120 V AC, 0.2 A (at) 230 V AC
- Efficiency 70 +%
- Output Ripple: 1% max.
- Switching frequency 200 kHz
- Line regulation: +/- 0.5%
- Load change: +/- 1%
- Operating temperature: -10°C to + 60°C.
- Storage temperature: -20°C to +85°C.
- Humidity: 5% to 90% non-condensing
- Weight: 192 g
- Product type
PoE injector
- PoE
Passive
- LAN data transfer rate
10 / 100 / 1000 MBit/s
- Width
55 mm
- Height
33 mm
- Length
85 mm
- Factory colour
Multicolour
0 W
0 h
60 W
- Weight
0.38
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1876767 Ubiquiti Networks POE-50-60W PoE injector 10 / 100 / 1000 MBit/s Passive
User & Safety Instructions
User & Safety Instructions 1876767 Ubiquiti Networks POE-50-60W PoE injector 10 / 100 / 1000 MBit/s Passive
Description
Ubiquiti Networks - passive PoE injector, 50 V, 60 Watt
Passive PoE adapter. Ubiquiti Networks offers Power-over-Ethernet (PoE) adapters for a wide range of Ubiquiti products.
This text is machine translated.
Passive PoE adapter. Ubiquiti Networks offers Power-over-Ethernet (PoE) adapters for a wide range of Ubiquiti products.
This text is machine translated.
Features
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN data transfer rates: 10.100.1000 Mbit/s.
- Compliance with industry standards: IEC 60950-1:2005+A1, UL60950-1, EN55022:2010, EN55024:2010
- Power over Ethernet (PoE) Voltage: 50 V.
- Power supply input voltage 90 - 260
- Power supply frequency 47/63.
