Ubiquiti Networks UACC-PoE+-2.5G Adapter
EAN:
Part number:
Item no:
Ubiquiti UACC-PoE+-2.5G 2.5 Gigabit Ethernet 48 V
Highlights & Details
- 10,100,1000,2500 Mbit/s
- Power over Ethernet (PoE)
- White
Technical specifications
- Product type
Adapter
- Width
62 mm
- Height
93 mm
- Depth
35 mm
- Factory colour
White
- Max. output current
0.65 A
- 10/100/1000 Mbps ports
2 x
- Weight
156 g
- UKCA
yes
- Operating temperature (T-T)
0 - 40 °C
- Total Power over Ethernet (PoE) budget
30 W
- Wall mountable
yes
- Operating temperature (T-T)
32 - 104 °F
- Power over Ethernet (PoE)
yes
- Power over Ethernet (PoE) voltage
48 V
- Number of products included
1 Stück(e)
- Operating relative humidity (H-H)
10 - 95 %
- Storage temperature (T-T)
-30 - 70 °C
- Surge protection
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3730677 Ubiquiti Networks UACC-PoE+-2.5G Adapter
Description
The Ubiquiti Unifi PoE injector provides devices with Power over Ethernet (PoE+) and ensures reliable connectivity for network applications. With an output power of 30 watts at a voltage of 48 V DC, this external device supports a seamless data transfer. The rugged design works in a temperature range from 0 °C to 40 °C and at a humidity of 10 to 95%, so that it can be installed in a variety of environments.
Equipped with shielded RJ-45 connections, the injector ensures signal integrity and at the same time offers protection functions such as surge protection and over current protection. It has been developed in accordance with various standards such as UL, FCC and RoHS and complies with the safety regulations. The efficient degree of efficiency of 87% provides for minimum power loss and makes it the first choice for the power supply of PoE-enabled devices.
This text is machine translated.
Equipped with shielded RJ-45 connections, the injector ensures signal integrity and at the same time offers protection functions such as surge protection and over current protection. It has been developed in accordance with various standards such as UL, FCC and RoHS and complies with the safety regulations. The efficient degree of efficiency of 87% provides for minimum power loss and makes it the first choice for the power supply of PoE-enabled devices.
This text is machine translated.
