USB 2.0 socket Micro-B RJ45 socket, mount M16 1310-1013-05 encitech Content: 1 pc(s)
EAN:
Part number:
Item no:
Product type
USB connector
Connector type
RJ45 socket, mount
Number of pins
5
USB type
Micro B
Connector standard
Micro-B USB
Datasheet (PDF)
Total (€ 43.69 / piece)
€ 43.69
plus VAT.
14-day return policy included
Technical specifications
- Type
1310-1013-05
- Product type
USB connector
- Connector type
RJ45 socket, mount
- Type
M16
- Number of pins
5
- USB type
Micro B
- Connector standard
Micro-B USB
- Connection
Cable + connector
- Connection
Micro USB 2.0 type B
- Type A
USB 2.0 port Micro B
- Type B
USB 2.0 connector Micro B
- Bore Ø
18 mm
- Case material
PA
- Manufacturer part #
1310-1013-05
- Factory colour
Black
- Content
1 pc(s)
- Cable Ø range
- Cable length
3.00 m
- Contact material
Gold plated
- Compatible with (details)
M16 thread
- RoHS-compliant
IP67
- Features
+ plastic cap
+ locknut
Documents & Downloads
Datasheet
Datasheet 1656509 USB 2.0 socket Micro-B RJ45 socket, mount M16 1310-1013-05 encitech Content: 1 pc(s)
