Vaillant 0020193190 Solar controller
EAN:
Part number:
Item no:
Technical specifications
- With circulation pump: Yes
- Self-venting circulation pump: No.
- Circulation pump delivery height: 10 m
- Volume flow meter: No.
- With safety valve: Yes
- With pressure gauge: Yes
- With thermometer: Yes
- With check valve: No.
- With connection expansion tank: Yes
- With automatic ventilation: No.
- Thermal insulation: Yes
- With wall holder: Yes
- With filling and emptying tap: Yes
- Design: Two-strand
- Max. Operating pressure 6 bar
- Max. Medium temperature (continuous operation): 130 °C.
- Max. Glycol -mixture:42%
- Pump length 110 mm
- Height: 325 mm
- Width 245 mm
- Depth: 175 mm
- Collector connection: Other
- Collector connector size: 3/4 in. (20)
- Connection memory: Other
- Size connection Memory: Other
- Expansion vessel connection: External gas cylindrical BSPP (ISO 228-1)
- Size Expansion Tank Connection: 3/4 in. (20)
- Material: Fittings: Brass
- Material: Brass
- Material seal: EPDM, aramide and inorganic fibers (NBR bound)
- With an electronic solar controller: No.
- Electronic solar controller expandable: No.
- With heat exchanger: No.
- Gravity circuit barrier: Yes
- Product type
Solar controller
- Type
Two-strand
- Dim
(W x H x D) 245.00 x 325.00 x 175.00 mm
- Width
245.00 mm
- Height
325.00 mm
- Depth
175.00 mm
- Weight
3.9000
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3148772 Vaillant 0020193190 Solar controller
Description
Solar station auroFLOW VMS 70 features, two-strand Solar station up to 70m2 collector surface, highly efficient solar circulation pump with PWM signal, integrated filling and emptying device, air separator with air release valve, shut-off ball valves with integrated gravity brake, check valve, 2 thermometers, 1 pressure gauges, pipe connections 3/4 flat-tight, Safety valve 6 bar to max. 70 m2 Collector surface Can be used for auroTHERM, auroTHERM exclusive, auroTHERM plus note: the storage temperature limiter is required (Article no. 0020193248)
