Buy Vaillant 0020201906 | Conrad Electronic

A brass non-return valve with a black plastic coating and a yellow warning label.

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Material of housing: Brass
Type separator: Dirt
Version: Horizontal / vertical
Suitable for heating: Yes
Suitable for cooling: No.
Pipe outer diameter 22 mm
Length 112 mm
Effective principle: Magnet
Flow rate 1.3 m³/h.
Suitable for closed systems: No.
With removable filter: Yes
Filter capacity 0.36 l
With integrated refill machine: No.
Magnet position: Internal
With insulation: No.

Product type: Magnetic filter

Material: Brass

Type: horizontal/vertical

UKCA: yes

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 3147610 Vaillant 0020201906

Description

Magnetic filter up to 1.3 m3/h for connection situation surface-mounting Filtering of magnetic and non-magnetic dust particles from the heating water (sludge separator). This protects individual components in the device. Dimensions 230x65x140 mm (HxBxD) Connection dimension is R3/4, can be used for atmoTEC exclusive, atmoTEC plus VCW, auroCOMPACT, ecoCOMPACT, ECOTEC exclusive, ECOTEC plus VC 10, 30 CS, ECOTEC plus VCI CS, ECOTEC plus VCW, ECOTEC plus VCW CS, VC 206/5-5, VC 146/5-5, VC 266/5-5 Can be used for new installation and replacement. Connection accessories for exchange installation included. Note: Only for use in the 14-27 kW power range

This text is machine translated.
