Value Server PSU 500 W 80 PLUS
EAN:
Part number:
Item no:
Inter-Tech APOWER U2A-B20500-S power supply 500 W 20+4 pin ATX high-grade steel
Highlights & Details
- PSU output 500 W
- PCI Express (6+2-pin) x
- Cable management 80 PLUS
Technical specifications
- Power rating
0 - 500 W
- PSU output power
500 W
- Product type
Server PSU
- 3.3V DC
25 A
- 5 V DC
25 A
- +12 V/DC (1)
16 A
- Certification
80 PLUS
- +12V DC (2)
40 A
- -12V / DC
0.5 A
- -5V DC
0.3 A
- +5V / DC SB
3 A
- 20+4-pin.
6
- 4+4 pin ATX/EPS 12V
1
- 4-pin floppy
1
- 4-pin Molex
4
- 5-pin SATA
2
- Dim
(W x H x D) 100 x 70 x 225 mm
- Weight
1.68 kg
- 24-pin
1
- 8-pin 12 V
1
- Output rating > 500 W
500 W
- Width
100 mm
- Height
70 mm
- Depth
225 mm
- Factory colour
Stainless steel
- Design height
70 mm
- Fan size
80 mm
- Power supply (details)
115 - 230 V
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2895960 Value Server PSU 500 W 80 PLUS
Description
High quality, 500 watts strong, server power supply with up to 90% efficiency.
This text is machine translated.
This text is machine translated.
Features
- Total power 500 W.
- AC input voltage 115 - 230 V
- Efficiency: 90%. Motherboard connector plug 20+4 pin ATX Purpose: Server
- Average operating time between failures (MTBF): 100000 h. Product color: Stainless steel
- Fan diameter 8 cm
- Number of fans: 1 fans. Width 100 mm
- Depth: 225 mm
- Height: 70 mm
