Technical specifications
- Conductor material: Copper
- Conductor class: Fine strands
- Wire identification: Colour
- Fire classification to EN 13501-6: ECA
- Wire diameter 1.3 mm
- Wire color: Red
- Working temperature -5 - 50 °C
- Oil resistant according to EN 60811-404: No.
- Cold resistant according to EN 60811-504+505+506: No.
- Smoke arm according to IEC 61034-2: No.
- AWG size: 0
- Product type
Wire core
- Cable type
H05V-K
- No. of leads
1 x
- Cross section (each core)
1 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
1 mm²
- Cross section
1 x 1 mm² + 1 x 1 mm²
- Cable features
Flat
Flexible
- Outside Ø
2.50 mm
- Factory colour
Red
- Content
100 m
- Nominal voltage
500 V
- Nominal voltage U0
300 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER EUP H05V-K 1 rt Ri.100
- Insulation material
Polyvinyl chloride
- Max. length sold by the metre
100 m
- Type
VER EUP H05V-K 1 rt Ri.100
Documents & Downloads
Datasheet
Datasheet 3337496 VER EUP H05V-K 1 rt Ri.100 Wire core H05V-K 1 x 1 mm² Red 100 m
User & Safety Instructions
User & Safety Instructions 3337496 VER EUP H05V-K 1 rt Ri.100 Wire core H05V-K 1 x 1 mm² Red 100 m
Description
According to EN 50525-2-31. Permanently protected laying in devices and in or on lights. Suitable for the installation in electrical installation pipe, on or under plaster, but only for signal and control circuits.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
