Technical specifications
- Conductor material: Copper
- Conductor class: Fine strands
- Fire classification to EN 13501-6: ECA
- Wire color: Black
- Working temperature 5 - 70 °C
- Oil resistant according to EN 60811-404: No.
- Cold resistant according to EN 60811-504+505+506: No.
- Smoke arm according to IEC 61034-2: No.
- Product type
Wire core
- Cable type
H07V-K
- No. of leads
1 x
- Cross section (each core)
1.50 mm²
- No. of leads (part 2)
1 x
- Cross section (each core) (part 2)
1.50 mm²
- Cross section
1 x 1.50 mm² + 1 x 1.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
2.95 mm
- Factory colour
Black
- Content
100 m
- Nominal voltage
750 V
- Nominal voltage U0
450 V
- Packaged
Yes
- Sold per metre
No
- Manufacturer part #
VER H07V-K 1,5 sw Eca Ri100
- Insulation material
Polyvinyl chloride
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER H07V-K 1,5 sw Eca Ri100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336657 VER H07V-K 1,5 sw Eca Ri100 Wire core H07V-K 1 x 1.50 mm² Black 100 m
Description
Complies with VDE 0281. For laying in dry rooms, in devices, switchgear and distributors, in pipes on or under plaster as well as in closed installation channels. In protected laying in and at lights. Max. operating temperature: 70 °C
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
