Technical specifications
- Conductor class: Fine strands
- Wire identification: Numbers
- With ground wire: No.
- Jacket material: Polyvinyl chloride (PVC)
- Rope element: No.
- Shield over wire element: Without
- Shield over stranding: Without
- Min Permitted bending radius, stationary use/fixed installation: 30 mm
- Cold resistant according to EN 60811-504+505+506: No.
- Smoke arm according to IEC 61034-2: No.
- Min Permissible bending radius, flexible use/free movement: 74 mm
- Product type
Power feed
- Cable type
YSLY-OZ
- No. of leads
2 x
- Cross section (each core)
0.50 mm²
- No. of leads (part 2)
2 x
- Cross section (each core) (part 2)
0.50 mm²
- Cross section
2 x 0.50 mm² + 2 x 0.50 mm²
- Cable features
Flat
Flexible
- Outside Ø
4.90 mm
- Factory colour
Grey
- Content
100 m
- Nominal voltage
500 V
- Packaged
Yes
- Sold per metre
Yes
- Manufacturer part #
VER YSLY-OZ 2x 0,5 Ri.100
- Insulation material
Polyvinyl chloride
- Min. temperature range (flexible installation)
-5 °C
- Max. temperature range (flexible installation)
70 °C
- Min. temperature range (fixed installation)
-30 °C
- Max. temperature range (fixed installation)
70 °C
- Max. length sold by the metre
100 m
- Type
VER YSLY-OZ 2x 0,5 Ri.100
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3336156 VER YSLY-OZ 2x 0,5 Ri.100 Power feed YSLY-OZ 2 x 0.50 mm² Grey 100 m
Description
Standard connection and connection line for control devices in and to processing machines under average mechanical load, in machine and plant as well as power plant construction, in heating and air-conditioning technology as well as in office machines and systems of data processing. For fixed laying, as well as for occasional, not constantly recurring movements, also in wet rooms. Outdoor use in compliance with the temperature range The galvanized steel wire mesh offers a high mechanical protection to the cable.
This text is machine translated.
This text is machine translated.
Hints
Made in Europe
