Victron Energy ASS300420200 Zigbee zu USB-Konverter Converter
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Power 5 V USB port
- Temperature range -40°C - 85°C
- UART baud rate 38400bps ）， Default （ 9600bps, 19200bps, 38400bps, 57600bps, 115200bps
- Radio frequency 2460MHz(default), 2405MHz – 2480MHz，Step：5MHz
- Protocol ZigBee 2007
- Distance Visible, open transmission distance : 1600 meters
- Operating current send：120mA(Max) receive：45mA（Max; Standby：） 40MA（Max
- Default：Router，PAN ID=0x199B，Channel=22（2460MHz）
- INTERFACE RS232:2-TX 3-RX 5-GND
- Product type
Converter
- Dim
(W x H x D) 70 x 24 x 50 mm
- Factory colour
Black
Silver
- Content
1 pc(s)
- Width
70 mm
- Height
24 mm
- Depth
50 mm
- Power supply (LOV)
via USB
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3059015 Victron Energy ASS300420200 Zigbee zu USB-Konverter Converter
User & Safety Instructions
User & Safety Instructions 3059015 Victron Energy ASS300420200 Zigbee zu USB-Konverter Converter
Description
Zigbee-to-USB converter & Zigbee to RS485:
This pair of Zigbee converter is intended to connect an energy meter wirelessly to an GX device.
This text is machine translated.
This pair of Zigbee converter is intended to connect an energy meter wirelessly to an GX device.
This text is machine translated.
Scope of delivery
- Converter
- USB cable
- Antenna
- User manual.
