Victron Energy BlueSolar M Charge controller MPPT 12 V, 24 V, 48 V 45 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Solar charge regulator MPPT Victron BlueSolar MPPT 150/45
- 45 A charging current
- 12/24/48 VDC
- Maximum PV-Idle voltage 150 V
Technical specifications
- Product type
Charge controller
- Nominal voltage
12 V
24 V
48 V
- Module power (max.)
2600 W
- Charging current (max.)
45 A
- Own power consumption
10 mA
- Control type
MPPT
- Dim
(L x W x H) 18.6 x 186 x 130 mm
- Weight
1.25 kg
- Module load (max.)
45 A
- Width
186 mm
- Height
130 mm
- Length
18.6 mm
- Depth
70 mm
- Connector
Pin contact
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3059077 Victron Energy BlueSolar M Charge controller MPPT 12 V, 24 V, 48 V 45 A
User & Safety Instructions
User & Safety Instructions 3059077 Victron Energy BlueSolar M Charge controller MPPT 12 V, 24 V, 48 V 45 A
Description
By using the latest and fastest technology, BlueSolar maximizes this energy generation and directs them in an intelligent way, in order to charge the batteries fully in as short a time as possible. The Blue Solar maintains the functional capability of the battery and in this way extends its life.
By continuously monitoring the voltage and current output of your Solar(PV) modules, the technology of the MPPT ensures that really all the power available is taken from the modules and stored. The advantage of this is most noticeable when the sky is partially covered and the light intensity changes constantly.
You can remotely control and monitor the extensive features of your SmartSolar MMPT charger with built-in Bluetooth by pairing it with your smartphone or other device via VictronConnect.
This text is machine translated.
By continuously monitoring the voltage and current output of your Solar(PV) modules, the technology of the MPPT ensures that really all the power available is taken from the modules and stored. The advantage of this is most noticeable when the sky is partially covered and the light intensity changes constantly.
You can remotely control and monitor the extensive features of your SmartSolar MMPT charger with built-in Bluetooth by pairing it with your smartphone or other device via VictronConnect.
This text is machine translated.
Features
- 45 A charging current
- 12/24/48 VDC
- Maximum PV-Idle voltage 150 V
- 10 mA internal consumption, IP43
- PV connection options
- Bluetooth
- Activation and deactivation of the charger via remote control
- Ultra-fast Maximum Power Point tracking (MPPT)
- Advanced Maximum Power point detection in the case of partial shadow.
- Excellent degree of efficiency
- Natural convection cooling
- Automatic detection of the battery voltage.
- Flexible charging algorithms
- Overtemperature protection and performance reduction at increased temperatures
Scope of delivery
- Solar charge regulator
- User manual.
Hints
Bluetooth® is a registered trademark of Bluetooth SIG, Inc. worldwide.
