Victron Energy Buck-Boost 50 DC/DC converter - 10 V, 12 V, 24 V, 30 V/50 A 600 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DC/DC converter Victron Buck-Boost 50
- 600 W
- Input 10-30 VDC
- Output 10-30 VDC / 50/25 A
Technical specifications
- Input voltage
10 - 30 V
- Product type
DC/DC converter
- No. of outputs
1 x
600 W
- Output voltage
10 V
12 V
24 V
30 V
- Max. output current
50 A
- Output current (max.) - rounded
50 A
- Dim
(L x W x H) 213 x 120 x 30 mm
- Weight
1.4 kg
- Content
1 pc(s)
- Width
120 mm
- Height
30 mm
- Length
213 mm
- Type
Buck-Boost 50
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3059019 Victron Energy Buck-Boost 50 DC/DC converter - 10 V, 12 V, 24 V, 30 V/50 A 600 W
Datasheet 3059019 Victron Energy Buck-Boost 50 DC/DC converter - 10 V, 12 V, 24 V, 30 V/50 A 600 W
User & Safety Instructions
User & Safety Instructions 3059019 Victron Energy Buck-Boost 50 DC/DC converter - 10 V, 12 V, 24 V, 30 V/50 A 600 W
Description
The Buck-Boost DC converter is a DC-DC converter for charging a 12V/24V service battery in vehicles with an intelligent alternator. As these generators (driven by the on-board electronics of the Euro 5 and 6 motors) do not always output the correct charging current, a DC-DC converter is decisive for the correct charging of the service battery.
This text is machine translated.
This text is machine translated.
Features
- Converters
- Programmable
- non insulated
- Connection M8
- Parallel connection (NA)
- IP22
- DC-DC-converter for charging a 12V or 24V battery in vehicles with an intelligent
- Alternating current generator
- System for detection when "engine running"
- Fully programmable
- A product for 12V, 24V and 12/24V systems
- Charging current and input current limitation
- Status indicators for input and output (LED)
Scope of delivery
- DC DC Converters
Hints
Tip: If you are unsure which voltage (V), current (A) and power (W) your devices require, this information can usually be found on the device's rear, on its box or in its instruction manual
