Victron Energy Charge controller PWM 12 V, 24 V 5 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Victron Blue Solar MPPT solar charge controller MPPT
- Fully programmable
- Battery Monitoring Function
- Reverse polarity protection for solar systems or batteries
Technical specifications
- Product type
Charge controller
- Nominal voltage
12 V
24 V
- Charging current (max.)
5 A
- Control type
PWM
- Dim
(W x H x D) 70 x 138 x 37 mm
- Weight
0.13 kg
- Width
70 mm
- Height
138 mm
- Depth
37 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1924389 Victron Energy Charge controller PWM 12 V, 24 V 5 A
User & Safety Instructions
User & Safety Instructions 1924389 Victron Energy Charge controller PWM 12 V, 24 V 5 A
Description
Programmable
The blue solar PWM-Pro Series is with your default settings ready for operation. You can, however, can also be completely programd:
- With the help of a computer and software (free on our website is available)
- With the corresponding blue Solar Pro Remote control panel (see features below).
Features
- Lighting Control, fully programmable.
- Three-stage battery charging (Konstantstromph..), fully programmable, Konstantspannungsph., Ladeerhaltungsspannungsph.
- Built-in battery monitoring function (remote control panel is to read the charging status).
Load output with switch-off function at a lower voltage and manual control (default setting).
- An optional external temperature sensor.
- Load output against overload and short circuits.
Polarity protection for solar system and/or battery.
This text is machine translated.
The blue solar PWM-Pro Series is with your default settings ready for operation. You can, however, can also be completely programd:
- With the help of a computer and software (free on our website is available)
- With the corresponding blue Solar Pro Remote control panel (see features below).
Features
- Lighting Control, fully programmable.
- Three-stage battery charging (Konstantstromph..), fully programmable, Konstantspannungsph., Ladeerhaltungsspannungsph.
- Built-in battery monitoring function (remote control panel is to read the charging status).
Load output with switch-off function at a lower voltage and manual control (default setting).
- An optional external temperature sensor.
- Load output against overload and short circuits.
Polarity protection for solar system and/or battery.
This text is machine translated.
