Victron Energy DC/DC converter 24 V DC - 24 V/5 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
DC/DC converter Victron Orion 24/24-5A (120 W)
- Remote-controlled on/off switching
- Adjustable output voltage: can also be used as a battery charger
- Short-circuit-proof and can be switched in parallel
Technical specifications
- Input voltage
16-35 V
- Product type
DC/DC converter
- Input voltage
24 V DC
- Output voltage
24 V
- Max. output current
5 A
- Output current (max.) - rounded
5 A
- Dim
(L x W x H) 47 x 113 x 100 mm
- Weight
0.42 kg
- Content
1 pc(s)
- Width
113 mm
- Height
100 mm
- Length
47 mm
- Type
ORI242410110R
- Efficiency
87 %
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1924499 Victron Energy DC/DC converter 24 V DC - 24 V/5 A
User & Safety Instructions
User & Safety Instructions 1924499 Victron Energy DC/DC converter 24 V DC - 24 V/5 A
Description
Remote-controlled on/off switching
The remote-controlled on/off switching makes a high current switch at the input wiring superfluous. The remote-controlled on/Aus-Anschluss can be used with an Energy Saving Switch or by the run/stop switch of the motor control (see manual).
Adjustable output voltage: can also be used as a battery charger
For example, to charge a 12 Volt starter or additional battery in an otherwise 24 V-System. All models are short-circuit-proof and can be parallel to the output current to
Increase. It can be an unlimited number of devices in parallel.
High temperature protected (protection at high temperatures)
At high ambient temperature, the output current is reduced.
This text is machine translated.
The remote-controlled on/off switching makes a high current switch at the input wiring superfluous. The remote-controlled on/Aus-Anschluss can be used with an Energy Saving Switch or by the run/stop switch of the motor control (see manual).
Adjustable output voltage: can also be used as a battery charger
For example, to charge a 12 Volt starter or additional battery in an otherwise 24 V-System. All models are short-circuit-proof and can be parallel to the output current to
Increase. It can be an unlimited number of devices in parallel.
High temperature protected (protection at high temperatures)
At high ambient temperature, the output current is reduced.
This text is machine translated.
