Victron Energy Grid-tie inverter MultiPlus C 12/1200/50-16 1200 W 12 V DC - 230 V AC Built-in charge controller
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Inverter / charger Victron MultiPlus C 12/1200/50-16
- Unique Power Assist function
- Continuous AC current (UPS function)
- Virtually unlimited power thanks to parallel switching
- Remote monitoring and control
Technical specifications
- Inverter (12V)
- Output 230 V ± 2%
- Frequency 50 Hz ± 0.1%
- Input voltage
9.5 - 17 V
- Product type
Grid-tie inverter
- Signal output type
Sine wave
- Output voltage
230 V AC
1200 W
- Input voltage
12 V DC
- Inputs
Cable
- Output
open ends
- Nominal load efficiency
93 %
- Output frequency
50 Hz
- Weight
10 kg
- Cooling method
Fan
- Width
214 mm
- Height
375 mm
- Length
21.4 mm
- Depth
110 mm
- Peak output power
2400 W
- Standby consumption
8 W
- Type
MultiPlus C 12/1200/50-16
- Features
Built-in charge controller
- Connector
Pin contact
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3402726 Victron Energy Grid-tie inverter MultiPlus C 12/1200/50-16 1200 W 12 V DC - 230 V AC Built-in charge controller
User & Safety Instructions
User & Safety Instructions 3402726 Victron Energy Grid-tie inverter MultiPlus C 12/1200/50-16 1200 W 12 V DC - 230 V AC Built-in charge controller
Description
The MultiPlus C 12/1200/50 from Victron (CMPN CMP121220000) is a device combination of 12V 1000W sine wave inverter and battery charger. The permanently integrated battery charger has a remarkable 35 A, which allows even large batteries to be quickly fully charged when the land/power supply is available. The 12 V sine wave voltage converter built into the MultiPlus converts your current from the battery into 230V AC. The real sine wave means that the power quality is perfect for sensitive electronic devices.
Extensive and flexible use
As it has an inverter and charger also a very fast 16 A transfer switch, it is an ideal inverter for mobile home, boat or yacht and for the mains-coupled range of the uninterruptible power supply in case of power fluctuations or power failures. Also for use in grid-connected home-consumption systems that only draw electricity from the supplier when the battery power is no longer sufficient or as a UPS solution in which the MultiPlus enters if the power from the network operator suddenly fails and thus ensures an uninterrupted power supply.
This text is machine translated.
Extensive and flexible use
As it has an inverter and charger also a very fast 16 A transfer switch, it is an ideal inverter for mobile home, boat or yacht and for the mains-coupled range of the uninterruptible power supply in case of power fluctuations or power failures. Also for use in grid-connected home-consumption systems that only draw electricity from the supplier when the battery power is no longer sufficient or as a UPS solution in which the MultiPlus enters if the power from the network operator suddenly fails and thus ensures an uninterrupted power supply.
This text is machine translated.
Features
- 2 charger outputs
- Parallel connection
- Three-phase operation
- Reliable and durable quality
- Integrated charge regulator
- Adaptive 4-stage charging characteristic
- High efficiency
- Power Assist
- High startup power
- Programmable relay
- Remote on/off switching possible
- Short-circuit-proof
- Temperature control
- Overload protection
- Alarm function
- LED indicator
- Reverse polarity protection
- Remote monitoring and control
- Overcharge protection
- Battery save mode
- Two DC outputs
- Temperature compensation
- Bearing mode
- Robust aluminum housing
Scope of delivery
- Inverter
- Temperature sensor
- User manual.
