Victron Energy Inverter 2000 VA 24 V DC - 230 V AC UPS function
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Victron inverters Phoenix C24/2000
- SinusMax-top technology
- The highest starting performance
- Virtually unlimited power by parallel connection and three-phase operation
Technical specifications
- Input voltage
19-33 V
- Product type
Inverter
- Signal output type
Sine wave
- Output voltage
230 V AC
2000 VA
- Input voltage
24 V DC
- Nominal load efficiency
92 %
- Output frequency
50 Hz
- Remote control
Yes (software)
- Weight
12 kg
- Width
255 mm
- Height
520 mm
- Length
25.5 mm
- Depth
125 mm
- Peak output power
4000 W
- Type
CIN242200000
- Features
UPS function
- Connector
Pin contact
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1924532 Victron Energy Inverter 2000 VA 24 V DC - 230 V AC UPS function
User & Safety Instructions
User & Safety Instructions 1924532 Victron Energy Inverter 2000 VA 24 V DC - 230 V AC UPS function
Description
SinusMax-top technology
The Phoenix Inverter Series was developed for commercial use; it is suitable for a variety of applications. The development aimed at an inverter with clean
Sine output at a high degree of efficiency. By applying the latest Hybrid HF technology it was possible a quality product with compact dimensions, low weight, each of the desired
Performance without any problem to deliver.
The highest starting performance
A key feature of the SinusMax technology is the particularly high starting power. With conventional HF technology is not possible. Phoenix inverter are able to high starting currents, for example,
Cooling compressors, tool motors and similar to cope with.
Virtually unlimited power by parallel connection and three-phase operation
Up to six inverter units can be connected in parallel to increase the performance. Six 24/3000 units can, for example, 15kW/18kVA at peak output. A three-phase operation is also possible.
Load switching to other AC power sources: The automatic load switch
For smaller services, we recommend the Filax Automatic switch. Computer and other sensitive electronic devices can be operated without interruption, since practically the switching times very short (less than 20 msec).
Computer Interfaces
All models have a RS-485 access. All you need is our MK2 Interface (see accessories). This interface provides the galvanic separation between the inverter and the
Computer and converts from RS-485 to RS-232. An RS232 to USB conversion cable is also available. With our software free of charge from our website www.victronenergy.com, VEConfigure
Can be downloaded, the inverter required in accordance with the be adjusted. This includes output voltage and frequency, the upper and lower voltage limits and the programming of the
Relays. The relay can be used, for example, to generate signals on special situations or even to start a generator can be used. The inverter can also participate in VENet, the innovative performance monitoring network of victron energy, or other computer-supported control and monitoring systems.
This text is machine translated.
The Phoenix Inverter Series was developed for commercial use; it is suitable for a variety of applications. The development aimed at an inverter with clean
Sine output at a high degree of efficiency. By applying the latest Hybrid HF technology it was possible a quality product with compact dimensions, low weight, each of the desired
Performance without any problem to deliver.
The highest starting performance
A key feature of the SinusMax technology is the particularly high starting power. With conventional HF technology is not possible. Phoenix inverter are able to high starting currents, for example,
Cooling compressors, tool motors and similar to cope with.
Virtually unlimited power by parallel connection and three-phase operation
Up to six inverter units can be connected in parallel to increase the performance. Six 24/3000 units can, for example, 15kW/18kVA at peak output. A three-phase operation is also possible.
Load switching to other AC power sources: The automatic load switch
For smaller services, we recommend the Filax Automatic switch. Computer and other sensitive electronic devices can be operated without interruption, since practically the switching times very short (less than 20 msec).
Computer Interfaces
All models have a RS-485 access. All you need is our MK2 Interface (see accessories). This interface provides the galvanic separation between the inverter and the
Computer and converts from RS-485 to RS-232. An RS232 to USB conversion cable is also available. With our software free of charge from our website www.victronenergy.com, VEConfigure
Can be downloaded, the inverter required in accordance with the be adjusted. This includes output voltage and frequency, the upper and lower voltage limits and the programming of the
Relays. The relay can be used, for example, to generate signals on special situations or even to start a generator can be used. The inverter can also participate in VENet, the innovative performance monitoring network of victron energy, or other computer-supported control and monitoring systems.
This text is machine translated.
