Victron Energy Inverter Phoenix 24/800 VE.direct NEMA 5-15R 800 W 24 V DC - 120 V AC

VE.Direct communication connection
The VE.Direct connector can be connected to the following devices:
• with a computer (VE.Direct to USB interface cable required)
• with Apple and Android smartphones, tablets, MacBooks or other devices (VE.Direct Bluetooth smart dongle required).

Fully configurable:
• Threshold values for triggering and resetting alarms when the battery is low.
• Threshold values for switching off and restarting at low battery voltage values.
• Dynamic shutdown: Load-dependant shutdown threshold
• Output voltage 210 - 245V
• Frequency 50 Hz or 60 Hz
• Threshold for ECO mode on/off and ECO mode sensor

Monitoring:
• input and output voltage, % load and alarms

Proven reliability
The complete bridging in addition with a ring transformer topology has proven itself for years. The inverters are short-circuit-proof and prevent overheating (whether due to overload or the
Ambient temperature).

High switch-on power
This is required for switching on loads such as voltage transformers for LED lamps, halogen lamps or power tools.

ECO mode
In ECO mode, the inverter switches to standby as soon as the load falls below a preset value (minimum load: 15W). In standby mode, the inverter then switches for a short time
Period (adjustable standard setting: Every 2.5 seconds). If the load exceeds a preset threshold value, the inverter remains switched on.

Remote-controlled on/off switching
A remote controlled on/off switch can be connected with a two-pole plug or between the positive terminal of the battery and the left contact of the two-pole plug.

Load switching to another AC source: The automatic transfer switch
For our low-power inverters, we recommend our Filax Automatic Transfer Switch. With the Filax, switching takes place very quickly (in less than 20 milliseconds), so that there is no interruption
Operation of computers and other electronic devices.
