Victron Energy Inverter Wechselrichter Victron Phoenix 24/1200 VE.direct NEMA 5-15R 1200 W 24 V - 120 V Sine wave
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Inverter Victron Phoenix 24/1200 VE.direct NEMA 5-15R
- 1200 W
- 24 VDC
Technical specifications
- Input voltage
18.4 - 34 V
- Product type
Inverter
- Signal output type
Sine wave
- Output voltage
120 V
1200 W
- Input voltage
24 V
- Inputs
Screw terminals
- Output
Terminal strip
- Outlets
1
- Output frequency
50 Hz
- Remote control
Optional
- Weight
7.4 kg
- Width
232 mm
- Height
117 mm
- Length
327 mm
- Standby consumption
3 W
- Type
Wechselrichter Victron Phoenix 24/1200 VE.direct NEMA 5-15R
- Features
Sine wave
Documents & Downloads
Datasheet
Datasheet 2878181 Victron Energy Inverter Wechselrichter Victron Phoenix 24/1200 VE.direct NEMA 5-15R 1200 W 24 V - 120 V Sine wave
Datasheet 2878181 Victron Energy Inverter Wechselrichter Victron Phoenix 24/1200 VE.direct NEMA 5-15R 1200 W 24 V - 120 V Sine wave
User & Safety Instructions
User & Safety Instructions 2878181 Victron Energy Inverter Wechselrichter Victron Phoenix 24/1200 VE.direct NEMA 5-15R 1200 W 24 V - 120 V Sine wave
Description
Inverters can be used to supply power to domestic appliances, which need 230 V AC. For this purpose, batteries are used for "recreational applications" or "car" batteries, which are rated at 12 V, 24 V or 48 V DC.
This text is machine translated.
This text is machine translated.
Features
- Own power draw 8.0 W / 1.5 W
- IP21
- LED
- Sine wave voltage
- Electronic safety function
- NEMA 5-15R AC SOCKET
- DC screw terminal
- Option (Bluetooth dongle, BMV)
Scope of delivery
- Inverter
