Relay Victron Cyrix Li load 24/48V-120A
- Continuous current and breaking capacity at 24 V / 120 A and 48 V / 40 A
Technical specifications
- Product type
SSR
- Type
Cyrix-Li-Last 24/48V-120A
- Width
46 mm
- Height
80 mm
- Length
46 mm
- Depth
80 mm
- Weight
110 g
- Output voltage
24 V
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
Datasheet 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
Datasheet 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
Datasheet 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
User & Safety Instructions
User & Safety Instructions 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
Conformity certificate
Conformity certificate 2878194 Victron Energy SSR Cyrix-Li-Last 24/48V-120A CYR020120450 46 mm x 46 mm x 80 mm x 80 mm
Description
The Cyrix-Li-ct functionality corresponds to that of the Cyrix-ct.
The Cyrix-Li-ct connects a lead-acid starter battery and a LiFePO4 battery:
- If the "Charge Disconnect" output of the VE. Bus BMS is high and
- If it measures 13.4 V (or 26.8 V) or more at its current terminals.
The Cyrix switches off immediately:
- When its control output reaches "free floating" (open circuit), a cell overvoltage
Or a cell overtemperature and/or
- If the battery voltage drops below 13.2 V.
Start Assist function: A short negative pulse closes the relay for 30 seconds (see figure on page 2).
A built-in TVS diode limits the peak voltage that can occur when the Cyrix suddenly occurs due to a
Switches off over-voltage or over-temperature.
The Cyrix battery coupler is a high-performance microprocessor-controlled relay that automatically switches batteries in parallel when one of them has reached a specified voltage (indicating that the battery is being charged) and that disconnects the batteries if the voltage drops below the maintenance voltage value (indicating that: one or both batteries are being discharged). Cyrix battery couplers are excellently suited for replacing separator diodes. Its main feature is that there is virtually no loss of voltage, so that the output voltage of the AC generators or battery chargers does not need to be increased.
