Victron Energy Trenntransformator 7000W 230V Isolation transformer (fixed voltage) 7000 W 230
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Isolating transformer Victron 7000 W 230V/230V
- Galvanic isolator
- A cost-effective solution to avoid galvanic corrosion
Technical specifications
- Power: 32 A
- Dim
(W x H x D) 258 x 362 x 218 mm
- Depth
218 mm
- Height
362 mm
- Width
258 mm
Manufacturer's standards (no certificate)
- Features
Inrush current limiter
- Type
Trenntransformator 7000W 230V
- Input voltage
230 V AC
- Output voltage (max.)
230 V
- Output voltage (min.)
230 V
7000 W
- System voltage
230 V
- Weight
28 kg
- UKCA
yes
- Product type
Isolation transformer (fixed voltage)
Documents & Downloads
Datasheet
Datasheet 1924533 Victron Energy Trenntransformator 7000W 230V Isolation transformer (fixed voltage) 7000 W 230
User & Safety Instructions
User & Safety Instructions 1924533 Victron Energy Trenntransformator 7000W 230V Isolation transformer (fixed voltage) 7000 W 230
Description
Indispensable in professional maritime energy systems to prevent electrolytic corrosion and are used mainly as devices to ensure a safe electrical system. Toroidal wound technology for low-noise operation with a high degree of efficiency. A soft start-up circuit ensures that the country protection switch when connecting is triggered.
This text is machine translated.
This text is machine translated.
Features
- Input 230 V, output 230V, Frequency: 50/60 Hz
