Viking Tech ARM05BTCW1002A SMD resistor 10 kΩ 0805 0.125 W 0.1 % 1 pc(s)
Part number:
Item no:
Product type
SMD resistor
Resistance
10 kΩ
Power rating
0.125 W
Content
1 pc(s)
Type
0805
Datasheet (PDF)
Highlights & Details
Viking Tech Corporation SMD thin-film 0805 0.125W 0.1% 10K
Our service for you
Technical specifications
- Application: Automotive and telecommunications applications, medical and industrial equipment, industrial measuring devices, industrial machines, various sensors, medical electronics
- MSL: 1 - unlimited
- Series: ARM05B
- Design 0805
- Delivery type: Belt
- Weight: 0.00471 g
- Resistance tolerance: ±0.1 %
- Rated output: 0.125 W
- Load reduction: Linear from 85°C to 155°C (0W)
- Max. OPERATING VOLTAGE (DC) 150 V DC
- Max voltage 300 V
- Qualification: AEC-Q200
- Product type
SMD resistor
- Type
0805
- Resistance
10 kΩ
- Power rating
0.125 W
- Tolerance ±
0.1 %
- Temperature coefficient
25 ppm/°C
- Length
2 mm
- Width
1.25 mm
- Height
0.55 mm
- Content
1 pc(s)
- Dim
(L x W x H) 2 x 1.25 x 0.55 mm
- RoHS-compliant
Yes
- Type
ARM05BTCW1002A
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3463969 Viking Tech ARM05BTCW1002A SMD resistor 10 kΩ 0805 0.125 W 0.1 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463969 Viking Tech ARM05BTCW1002A SMD resistor 10 kΩ 0805 0.125 W 0.1 % 1 pc(s)
Description
Viking RG2012P thin film resistors
This text is machine translated.
This text is machine translated.
Features
- • Temperature coefficient (TC) ±25ppm/°C.
- • Tolerance of 0.1%
- • Extended sulfur resistance verified according to ASTM B 809
