Visaton R 10 ND - 8 Ohm 4 inch 10 cm Wideband speaker 10 W 8 Ω Black
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Visaton R 10 ND Broadband loudspeaker
- Load capacity RMS/max. 10/20 W.
- 10 cm (4") broadband speaker
- High degree of efficiency
- Water-resistant membrane
Technical specifications
- Product type
Wideband speaker
- Speaker size (cm)
10 cm
- Speaker size (inch)
4 inch
- RMS capacity
10 W
- Max. load
20 W
- Max. frequency
16000 Hz
- Min. frequency
120 Hz
- Impedance
8 Ω
- Sound pressure
92 dB
- Recess diameter
117 mm
- Recess depth
35.5 mm
- Weight
113 g
- Factory colour
Black
- Frequency range
120 Hz - 16000 Hz
Documents & Downloads
Datasheet
Datasheet 2141394 Visaton R 10 ND - 8 Ohm 4 inch 10 cm Wideband speaker 10 W 8 Ω Black
User & Safety Instructions
User & Safety Instructions 2141394 Visaton R 10 ND - 8 Ohm 4 inch 10 cm Wideband speaker 10 W 8 Ω Black
Description
10 cm (4") broadband speaker with a very high degree of efficiency and balanced frequency response with high-tone rise. Very good speech understanding with this. Water-resistant membrane and rubber seal. Especially suitable as a control speaker for electronic devices and as a build-in speaker for public transport and facilities.
This text is machine translated.
This text is machine translated.
Features
- Music power 20 W
- Transmission range (-10 dB) - 120-16000 Hz
- Average Sound pressure level 92 dB (1 W/1 m)
- Low weight thanks to neodymium magnet
- Water-resistant membrane
- Metal construction, corrosion-resistant
- High electrical efficieny
- Magnetic shielding.
