Vishay P20 50 10R 10% AEY Wire-wound pot Wire-wound 30 W 10 Ω 1 pc(s)
Part number:
Item no:
Product type
Wire-wound pot
Potentiometer features
Wire-wound
Resistance
10 Ω
Resistance characteristic
linear
Power rating
30 W
Datasheet (PDF)
Highlights & Details
Vishay 30W high panel Wire wound potentiometer mono linear 10R
- 10 Ω
- linear
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series P20
- Design: Horizontal
- Weight: 70 g
- Height, socket 31 mm
- Diameter, base 43 mm
- Length, shaft 35 mm
- Diameter, Shaft 6 mm
- Axle: Metal
- Resistance tolerance: ±10 %
- Resistance curve: Linear
- Rated output: 30 W
- Breakdown voltage (RMS) 2,500 V
- Mechanical rotation angle 290 °
- Electrical angle of rotation 276 °
- Stop strength 100 Ncm
- Torque 4 Ncm
- Product type
Wire-wound pot
- Potentiometer features
Wire-wound
- Resistance
10 Ω
- Resistance characteristic
linear
- Power rating
30 W
- Connection
Solder tag
- Mechanical angle
290°
- Electrical angle
276°
- Torque (max.)
4 Ncm
- Impact tolerance
100 Ncm
- Axle length
35 mm
- Axle type
Metal
- Axle Ø
6 mm
- Length
35 mm
- Height
31 mm
- (Ø)
43 mm
- Tolerance ±
10 %
- Content
1 pc(s)
- Type
P20 50 10R 10% AEY
- Dim
(Ø x H) 43 mm x 31 mm
- RoHS-compliant
Yes
Documents & Downloads
Datasheet
Datasheet 3465771 Vishay P20 50 10R 10% AEY Wire-wound pot Wire-wound 30 W 10 Ω 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3465771 Vishay P20 50 10R 10% AEY Wire-wound pot Wire-wound 30 W 10 Ω 1 pc(s)
Description
P20 Vishay Series Wire Potentiometer
This text is machine translated.
This text is machine translated.
Features
- • High-load wire potentiometer
- • High performance
- • Concrete coating
- • Slider made of silver rivet
- • Connection via tin-plated solder lugs
Scope of delivery
- P20 50 10R 10% AEY.
