Vishay RCH25S10001JS06 HV resistor 10 kΩ Radial lead 25 W 5 % 1 pc(s)
Part number:
Item no:
Product type
HV resistor
Resistance
10 kΩ
Power rating
25 W
Content
1 pc(s)
Type
Radial lead
Datasheet (PDF)
Highlights & Details
Vishay Power thick layer 25W 5% 10K
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series RCH25
- Delivery form: Loose
- Weight: 7 g
- Resistance tolerance: ±5 %
- Nominal load, with heat sink 25 W
- Nominal load without heat sink 4 W
- Rated output: 25 W
- Max. OPERATING VOLTAGE (DC) 550 V DC
- Max. OPERATING VOLTAGE (AC) 550 V AC
- Test voltage 3,500 V
- Thermal resistance 1.4 K/W.
- Climate category: 55/125/56
- Product type
HV resistor
- Type
Radial lead
- Resistance
10 kΩ
- Power rating
25 W
- Tolerance ±
5 %
- Temperature coefficient
150 ppm/°C
- Length
28.0 mm
- Width
27.0 mm
- Height
9.0 mm
- Content
1 pc(s)
- Dim
(L x W x H) 28.0 x 27.0 x 9.0 mm
- RoHS-compliant
Yes
- Type
RCH25S10001JS06
- Operating temperature (max.)
125 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3464077 Vishay RCH25S10001JS06 HV resistor 10 kΩ Radial lead 25 W 5 % 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3464077 Vishay RCH25S10001JS06 HV resistor 10 kΩ Radial lead 25 W 5 % 1 pc(s)
Description
Thick film resistors 25W 5%
This text is machine translated.
This text is machine translated.
Features
- • 25W at 25°C and fitted heat sink (optional)
- • Compact design
- - easy installation
- • High insulation resistance 10^6 MOhm
