Vishay RH02510K00FE05 Resistance wire 10 kΩ Axial lead 25 W 1 % 1 pc(s) Bulk
Part number:
Item no:
Packaging type
Bulk
Product type
Resistance wire
Resistance
10 kΩ
Power rating
25 W
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Vishay wire BW. In metal housing 25W 1% 10K
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series RH025
- Delivery form: Loose
- Total length: 49.23 mm.
- Weight: 12 g
- Resistance tolerance: ±1 %
- Rated output: 25 W
- Load reduction: Linear from 25°C to 250°C.
- Insulation voltage 1,000 V
- Packaging type
Bulk
- Product type
Resistance wire
- Type
Axial lead
- Resistance
10 kΩ
- Power rating
25 W
- Tolerance ±
1 %
- Temperature coefficient
20 ppm/°C
- Length
27.0 mm
- Width
27.4 mm
- Height
13.9 mm
- Max. temperature
250 °C
- Min. temperature
25 °C
- Insulation resistance
10^4 MΩ
- Threshold voltage
1.000 V
- Content
1 pc(s)
- Dim
(L x W x H) 27.0 x 27.4 x 13.9 mm
- RoHS-compliant
Yes
- Type
RH02510K00FE05
- Operating temperature (max.)
250 °C
- Operating temperature (min.)
-55 °C
- Certification marks
MIL-PRF-18546
Documents & Downloads
Datasheet
Datasheet 3464086 Vishay RH02510K00FE05 Resistance wire 10 kΩ Axial lead 25 W 1 % 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3464086 Vishay RH02510K00FE05 Resistance wire 10 kΩ Axial lead 25 W 1 % 1 pc(s) Bulk
Description
Wire resistance in metal housing 1% 25W
This text is machine translated.
This text is machine translated.
Features
- Wire resistance in aluminum casing
- Hermetically thick construction
- Heat sink with high thermal conductivity
- Suitable for chassis mounting for enhancing the cooling effect
- All connections point-welded
- Meet MIL-PRF-18546
