Vishay RTO020FR1000JTE3 HV resistor 0.1 Ω TO 220 20 W 5 % 1 pc(s) Piece
Part number:
Item no:
Packaging type
Piece
Product type
HV resistor
Resistance
0.1 Ω
Power rating
20 W
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Vishay Thick Film TO220 20W 5% 0R1
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series RTO20F
- Design: TO220
- Delivery form: Rod
- Total height 28.7 mm
- Weight: 2.2 g
- Resistance tolerance: ±5 %
- Nominal load, with heat sink 20 W
- Nominal load without heat sink 2 W
- Rated output: 20 W
- Max. OPERATING VOLTAGE (DC) 250 V DC
- Max. OPERATING VOLTAGE (AC) 250 V AC
- Test voltage 2,000 V
- Thermal resistance 6.5 K/W.
- Climate category: 55/155/56
- Packaging type
Piece
- Product type
HV resistor
- Type
TO 220
- Resistance
0.1 Ω
- Power rating
20 W
- Tolerance ±
5 %
- Temperature coefficient
250 ppm/°C
- Length
10.0 mm
- Width
4.5 mm
- Height
15.0 mm
- CS
5.08 mm
- Max. temperature
155 °C
- Min. temperature
-55 °C
- Threshold voltage
2.000 V
- Content
1 pc(s)
- Dim
(L x W x H) 10.0 x 4.5 x 15.0 mm
- RoHS-compliant
Yes
- Type
RTO020FR1000JTE3
- Mounting type
PCB mount
- Operating temperature (max.)
155 °C
- Operating temperature (min.)
55 °C
Documents & Downloads
Datasheet
Datasheet 3464085 Vishay RTO020FR1000JTE3 HV resistor 0.1 Ω TO 220 20 W 5 % 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3464085 Vishay RTO020FR1000JTE3 HV resistor 0.1 Ω TO 220 20 W 5 % 1 pc(s) Piece
Description
Thick film resistors 20W 5% TO220
This text is machine translated.
This text is machine translated.
Features
- • 20W at 25°C and fitted heat sink (optional)
- • Low inductance
- • Compact design
- • Simple mounting through TO220 housing
