Stroke drawing/circuit diagram
Stroke drawing/circuit diagram
Vishay Schottky rectifier 11DQ09 DO 204AL 90 V Single
EAN:
Part number:
Item no:
Enclosure
DO 204AL
Reverse voltage U(R)
90 V
Forward current I(F)
1.1 A
Configuration (diode)
Single
Forward voltage U(F)
850 mV
Datasheet (PDF)
120 Piece(s)
Sales and shipping:
Number
Minimum order quantity: 10
Total (€ 0.20 / piece)
€
Technical specifications
- Type
11DQ09
- Enclosure
DO 204AL
- Manufacturer
Vishay
- Manuf. code
VIS
- Reverse voltage U(R)
90 V
- Forward current I(F)
1.1 A
- Reverse leakage current I(r)
500 µA
- Configuration (diode)
Single
- Forward voltage U(F)
850 mV
- Forward voltage reference
1 A
- Reverse leakage current I(r) reference
90 V
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
+150 °C
- Mounting type
Through-hole
- Content
1 pc(s)
- Type
Schottky diode
- Product type
Schottky rectifier
