Vishay TLUO2401 LED wired Red Rectangular 1.8 mm 5 mcd 40 ° 30 mA 2 V
EAN:
Part number:
Item no:
Product type
LED wired
Forward voltage U(F)
2 V
Forward current I(F)
30 mA
Casing
1.8 mm
Type
Radial lead
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
15
-
€ 0.17
45
12% = € 0.02
€ 0.15
75
18% = € 0.03
€ 0.14
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 15
Total (€ 0.17 / piece)
€ 0.45
-62 %
€ 2.55
plus VAT.
14-day return policy included
Technical specifications
- Series: TLU (G, O, Y) 240 x
- Product type
LED wired
- Type
TLUO 2401
- Factory colour
Red
- Forward voltage U(F)
2 V
- Forward current I(F)
30 mA
- Casing
1.8 mm
- Type
Radial lead
- Light intensity I(V)
5 mcd
- Wavelength
618 nm
- Radiation angle
40°
- Type (LEDs)
Diffused
- Technology
GaAsP
GaP
- Lens type
Rectangular
- Dim
(L x W x H) 29.7 x 3.3 x 2.4 mm
- Min. temperature
-40 °C
- Max. temperature
+100 °C
- Length
29.7 mm
- Width
3.3 mm
- Height
2.4 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 1125482 Vishay TLUO2401 LED wired Red Rectangular 1.8 mm 5 mcd 40 ° 30 mA 2 V
User & Safety Instructions
User & Safety Instructions 1125482 Vishay TLUO2401 LED wired Red Rectangular 1.8 mm 5 mcd 40 ° 30 mA 2 V
Description
Hints
All standard LED chips require a current-limiting resistor/constant current power source.
