Buy Vogt Verbindungstechnik 3614a Ring terminal Cross section (max.)=1 mm² Hole Ø=4.3 mm Partially insulated Red 1 pc(s)

There is a Conrad shop in your region. You can shop in your own language, have access to your local customer service and enjoy local transport for your purchase.

Go to local shop

Conrad
To search for the product, enter a catchphrase, an article number, an EAN or a part number
My account

Log in / Register
Shopping cart

Subscribe to the newsletter and receive a €5 voucher Subscribe to the newsletter and receive a €5 voucher
Procurement

Order & eProcurement

All order and procurement services
Services

All Services
Offers %

Red cable lug with metal eyelet, typical connection accessory for electrical connections.

Technical drawing of a component with front and side views. Dimensions are labelled with D, R, L, S, T, D4, D6.

1/2

Image similar

Our service for you

Datasheet (PDF)

4040 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 30

Total (€ 0.12 / piece)

€

Report legal concerns

Highlights & Details

Vogt Verbindungstechnik 3614a Ring terminal Cross section (max.)=1 mm² Hole Ø=4.3 mm Partially insulated Red 1 pc(s)

0.50 - 1 mm²

Technical specifications

Manufacturer part #: 3614a

Type: 3614a

max. cross section: 1 mm²

Min. cross section: 0.50 mm²

Content: 1 pc(s)

Factory colour: Red

Cross-section range: 0.50 - 1 mm²

Insulation type: Partially insulated

Thread size: M4

Material (details): Tinned electrolytic copper (DIN 46237 / UL-No. E235797)

Hole Ø: 4.3 mm

Insulation material: PA

Contact material: Cathode copper, tin plated

RoHS-compliant: Yes

Support sleeve: No

Product type: Ring terminal

Documents & Downloads

Datasheet

Datasheet 1226305 Vogt Verbindungstechnik 3614a Ring terminal Cross section (max.)=1 mm² Hole Ø=4.3 mm Partially insulated Red 1 pc(s)
