Buy Vogt Verbindungstechnik 3826F08.68 Blade receptacle PCB-SMD Connector width: 4.8 mm Connector thickness: 0.8 mm 180 ° No

Silver metal clip with two parallel clips mounted on a metallic base, commonly used in electrical connections.

Image similar

Technical drawing of a connector with dimensional specifications: L, W1, W2, D, H, C, L2, W. Shows the shape and dimensions of the plug.

1/2

Image similar

Product type

Blade receptacle

Connector width

4.8 mm

Insulation type

Not insulated

Content

1 pc(s)

Factory colour

Metal

Datasheet (PDF)

Fast track dispatch on Wed, 30 Sep

407 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Quantity (Piece(s))

Savings

Package size (plus VAT.)

Volume discounts vary depending on the seller

You save € 0.00

Number

Piece(s)

Minimum order quantity: 15

Total (€ 0.19 / piece)

€ 0.24

-21 %

€ 2.85

plus VAT.

14-day return policy included

Report legal concerns

Highlights & Details

Vogt Verbindungstechnik 3826F08.68 Blade receptacle PCB-SMD Connector width: 4.8 mm Connector thickness: 0.8 mm 180 ° Not insulated Metal 1 pc(s)

Metal
4.8 mm x 0.8 mm
-

Our service for you

Technical specifications

Product type: Blade receptacle

Connector width: 4.8 mm

Factory colour: Metal

Connector thickness: 0.8 mm

Insulation type: Not insulated

Connection angle: 180°

Contact material: Brass tin plated

Content: 1 pc(s)

Manufacturer part #: 3826F08.68

Size: 4.8 x 0.8 mm

Features: PCB-SMD

Type: 3826F08.68

Material (details): Brass, tin-plated

Type: 4.8 x 0.8 mm

Cross section: -

Connection: -

Documents & Downloads

Datasheet

Datasheet 730040 Vogt Verbindungstechnik 3826F08.68 Blade receptacle PCB-SMD Connector width: 4.8 mm Connector thickness: 0.8 mm 180 ° No

Description

Tin-plated brass.
