Highlights & Details
Voltcraft IPC-3 Cylindrical Battery Charger
- Suitable for NiCd, NiMH and Li-Ion batteries
- Battery quick-test function
- Selectable charging/discharge current
- Battery test/refresh function
Technical specifications
- Selectable charging current: 200, 300, 500, 700, 1000, 1500, 2000 mA
- 2000 mA current only available at the two outer slots
- Selectable discharge current: 200, 300, 500, 700 mA
- Max. charge capacity: 20000 mAh
- Power cable length: approx 145 cm
- Charger input: 12 V
- C, 26500- and 26650-type batteries recharging using the two outer slotsC batteries only
- Matching rechargeable battery
Li-ion
NiCd
NiMH
- Product type
Charger for cylindrical cells
- Suitable for battery size
10440
14500
16340
16650
17355
17500
17670
18490
18500
18650
Show more
- Charging slots
4
- AAA
4
- AA
4
- Operating voltage
100 - 240 V
- Discharge current
700 mA
- Max. charging current per slot
1000 mA
- Charger features
Faulty battery detection
Battery recognition
Battery refresher/regenerator
Automatic battery test
Individual slot monitoring
Discharger function
Trickle charging
Graphic display
Selectable charging current
Battery voltage based auto switch-off
Show more
- Charging time for AAs
70 Min.
- Width
100 mm
- Height
42 mm
- Depth
151 mm
- Weight
230 g
- Dim
(W x H x D) 100 x 42 x 151 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1403321 VOLTCRAFT IPC-3 Charger for cylindrical cells Li-ion, NiCd, NiMH 10440, 14500, 16340, 16650, 17355, 17500, 17670, 18490,
User & Safety Instructions 1403321 VOLTCRAFT IPC-3 Charger for cylindrical cells Li-ion, NiCd, NiMH 10440, 14500, 16340, 16650, 17355, 17500, 17670, 18490,
Conformity certificate
Conformity certificate 1403321 VOLTCRAFT IPC-3 Charger for cylindrical cells Li-ion, NiCd, NiMH 10440, 14500, 16340, 16650, 17355, 17500, 17670, 18490,
Warranty Terms
Warranty Terms 1403321 VOLTCRAFT IPC-3 Charger for cylindrical cells Li-ion, NiCd, NiMH 10440, 14500, 16340, 16650, 17355, 17500, 17670, 18490,
Description
The IPC-3 smart charger is suitable for NiCd and NiMH batteries, as well as for the increasingly popular cylindrical Li-Ion batteries. This includes all common 18650-type batteries as well as 14500, CR-123A and other battery sizes that can be charged in the four slots at the same time The device is easy to use. Just insert the batteries and leave everything else to the charger. The charger comes with an additional battery test function that auto-detects battery condition and also whether a battery might have been inserted incorrectly. If necessary, the charger enables the refresh function restoring the battery back to full capacity, extending battery life span in the process. A backlit LC screen displays all relevant battery parameters and shows you the charging progress.
Features
- Microprocessor-controlled
- Battery voltage based auto switch-off
- Individual slot monitoring
- Selectable charging/discharge current
- Automatic trickle charge
- Battery quick-test function
- Discharge function
- Temperature monitoring
- Detects defect or incorrectly inserted batteries
- Overcharge protection
- Easy to operate: 4 keys only
- Overload protection
- User-friendly backlit display
Scope of delivery
- IPC-3
- Power supply unit
- User manual.
