Votronic Extender 3n1 1440 Battery monitoring
EAN:
Part number:
Item no:
Technical specifications
- Rated voltage 12/24VDC
- Operating voltage range 8 - 32 V
- Power consumption in standby, typical 0.7 mA
- Power consumption during activity, typical 10 mA
- Ambient conditions, air humidity max. 95 % RF, non-condensing
- Weight approx. 37 g
- Product type
Battery monitoring
- Length
75 mm
- Width
47 mm
- Height
24 mm
- Dim
(L x W x H) 75 x 47 x 24 mm
- Weight
0.4 kg
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3062546 Votronic Extender 3n1 1440 Battery monitoring
Description
It holds the data of up to three VOLTCRAFT solar controllers (or VBCS Triple) so that they can be shown in a single display, e.g. LCD Solar Computer S, LCD Charge Control S, VPC with solar function or Bluetooth Connector S-BC. The usual LCD display can still be used. The Solar Data Extender can be installed at any time later. It has three independent inputs (IN1, IN2, IN3). The signals are supplied together via the output (OUT). A solar display (e.g. LCD Solar Computer S) can be connected there. It can be easily connected between the solar charge regulator and the solar display (e.g. LCD SOLAR COMPUTER S) using the modular cable supplied.
