W & P Products 186-08-1-50-00 -1-50 186-08-00 IC socket connector Contact spacing: 2.54 mm Number of pins: 8 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
3
-
€ 1.25
9
8% = € 0.10
€ 1.15
15
11% = € 0.14
€ 1.11
Volume discounts vary depending on the seller
You save € 0.00
Number
Minimum order quantity: 3
Total (€ 1.25 / piece)
€ 3.75
plus VAT.
Technical specifications
- Material: UL 94 V-0, (contact), gold-plated
- Type
-1-50 186-08-00
- Number of pins
8
- CS
2.54 mm
- Min. temperature
-55 °C
- Max. temperature
125 °C
- RoHS-compliant
Yes
- Content
1 pc(s)
- Product type
IC socket connector
Documents & Downloads
Datasheet
Datasheet 719374 W & P Products 186-08-1-50-00 -1-50 186-08-00 IC socket connector Contact spacing: 2.54 mm Number of pins: 8 1 pc(s)
Description
The socket connector is suitable, among other things, ideally suited for construction of IC-sockets. Round pins diameter 0.40 - 0.56 mm or square pins 0.25 x 0.45 mm.
This text is machine translated.
This text is machine translated.
Hints
Contact turned.
