Wachendorff DA9602R0 Temperature controller J, K, T, E, N, R, S, B, Pt100 (L x W x H) 35 x 96 x 48 mm
EAN:
Part number:
Item no:
Product type
Temperature controller
Operating voltage
110 V AC
230 V AC
No. of relay outputs
2
Sensor type
J
K
T
E
N
R
S
B
Pt100
Mounting type
Recess-mount
Number
Total (€ 193.27 / piece)
€ 201.68
€ 193.27
plus VAT.
Only 1 Piece(s) available
Highlights & Details
Wachendorff DA9602R0 Temperature controller J, K, T, E, N, R, S, B, Pt100 (L x W x H) 35 x 96 x 48 mm
- 2 Alarm outputs
- Extremely low mounting depth of 32 mm
- Programming via keyboard or software (USB port)
Technical specifications
- Sensor supply 24 V/DC/50 mA
- Linear Inputs: 0 to 5/10 V, 0/4 to 20 mA, 0 to 50 mV
- Sampling rate: 55 Hz
- Display area measured value: -1.999 to 30,000
- Display area sum: 0 up to 999 999,999 (alternating display)
- Internal resolution: 65,535 steps (16 Bit)
- Display resolution: 32,000 steps
- Product type
Temperature controller
- Type
DA9602R0
- Operating voltage
110 V AC
230 V AC
- No. of relay outputs
2
- Outputs
2 normally open contact with separate earth 1.5 A at 240 V/AC/30 V/DC
- Dim
(L x W x H) 35 x 96 x 48 mm
- Height
48 mm
- Length
35 mm
- Width
96 mm
IP65 (front)
- Sensor type
J
K
T
E
N
R
S
B
Pt100
- Manufacturer part #
DA9602R0
- Recess depth
32 mm
- Mounting type
Recess-mount
- Assembly dimensions
96 x 48 mm
- Sensor type
Thermocouple type J, K, T, N, R, S, B, E, and Pt100 temperature sensor
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 192849 Wachendorff DA9602R0 Temperature controller J, K, T, E, N, R, S, B, Pt100 (L x W x H) 35 x 96 x 48 mm
Description
Universal Display with an input for almost all commercially available temperature sensors and process signals. With the 24V/DC-sensor supply up to 50 mA, the integrated summing function and 2 relay outputs, this display for almost all applications. In addition to the very low installation depth, the IP65 front, the removable terminal blocks, and the brilliant display with 16 mm digit height captivates this display through their excellent price/performance ratio. The programming is done with a software via USB interface or keyboard.
This text is machine translated.
This text is machine translated.
Features
- Universal display in the 96 x 96, 96 x 48 mm format
- Universal input for process signals, thermocouples, Pt100
- 5-digit LED display, red with 16mm high digits
- Total function
- Saves min./max. values.
Scope of delivery
- Universal digital display since 9602 RO
- Fasteners
- Gasket
- Operating instructions.
