Buy Wachendorff LD200600 0 -25 k Hz

Electronic display boards with red numbers. The larger one shows '-18,235', the smaller one '-863.98'.<br><br>Note: I've adjusted the number formatting to British English style, using a comma as the thousands separator and maintaining the decimal point.

Collection

Two electronic display boards with large, red LED digits in an industrial design show the numbers '873816' and '863.98'.

1/2

Collection

Datasheet (PDF)

Dispatches on Tue, 15 Sep

1 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 726.89 / piece)

€ 726.89

plus VAT.

Only 1 Piece(s) available

Report legal concerns

Highlights & Details

Meter LD200600

Brilliant dimmable large-LED-display?Universal voltage supply AC or DC
strong casing in Aluminium safety type IP65

Technical specifications

Reading type: Frequency

Reading range (min.): 0 Hz

Type: LD200600

Reading range (max.): 25000 Hz

Display technology: LED

: IP65

Operating voltage: 24 V DC

Dim: (W x H x D) 406.4 x 101.6 x 57.2 mm

Width: 406.4 mm

Height: 101.6 mm

Interfaces: CMOS

Digit height: 57 mm

Depth: 57.2 mm

Digits: 6

Display (details): LED

Power supply (details): 50 - 250 V/AC or 21.6 - 250 V DC

Reading range: 0 -25 k Hz

Documents & Downloads

Datasheet

Datasheet 129098 Wachendorff LD200600 0 -25 k Hz

User & Safety Instructions

User & Safety Instructions 129098 Wachendorff LD200600 0 -25 k Hz

Description

The Industries-meter LD is cost effective large display for Impulse signal. It was designed with sturdy aluminium casing and the high safety type IP 65 for industrial use. Input frequency max. 25 kHz fits all commercial sensors Free scalable and simple programming via front keys Counting function as pure piece reader or as counter with Phase discriminator/ Staple counter Tachometer with period measurement. 2 free programmable Relays outputs. The device is quickly and safely projected directly via 3 keys

Features

Inputs for NPN-, PNP- Sensors, CMOS, TTL, potencial free contact, Permanent magnet sensors
Adjustable via DIP-switch
Damping at 50 Hz adjustable
Sensor supply 24 V/DC.
