WAGO 2000-1206 Continuity 3.50 mm Pull spring Yellow 100 pc(s) Package
EAN:
Part number:
Item no:
Packaging type
Package
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1 mm²
Datasheet (PDF)
Highlights & Details
2-conductor through terminal
- 2000 1206
- Industrial packaging with 100 pieces
- This text is machine translated.
Technical specifications
- Packaging type
Package
- Product type
Continuity
- Features
Complies with ATEX Ex-e II standards
- Connection
Pull spring
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (inflexible) (max.)
1 mm²
- AWG (min.)
24
- AWG max.
16
- Clamp width
3.50 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Yellow
- Nominal current
13.5 A
- Nominal current - rounded value
13.5 A
- Nominal voltage
800 V
- Stripping length (max.)
9 mm
- Manufacturer part #
2000-1206
- Content
100 pc(s)
- Industrial packaging
Yes
- Type
2000-1206
- Dim
(L x W x H) 3.50 x 3.50 x 32.90 mm
- Width
3.50 mm
- Height
32.90 mm
- Length
3.50 mm
- Contamination level
3
- Weight
3.58 g
- Connector colour
Yellow
DIN rail (top hat rail) 35 mm
Yellow
3.5
48.5 mm
32.9 mm
800 V
105-105 °C
V0
TRUE
Spring clamp connection
Spring clamp connection
1
2
FALSE
0.5-1.5 mm²
0.5-0.75 mm²
0.14-1.5 mm²
0.14-1 mm²
Thermoplastic
13.5 A
TRUE
- UKCA
not relevant
