Image similar
Image similar
WAGO 2010-1304 Continuity 10 mm Pull spring Configuration: N Blue 1 pc(s)
EAN:
Part number:
Item no:
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
10 mm²
Nominal current - rounded value
57 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 4.03
5
7% = € 0.27
€ 3.76
10
9% = € 0.37
€ 3.66
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 4.03 / piece)
€ 4.03
plus VAT.
14-day return policy included
Highlights & Details
WAGO 2010-1304 Continuity 10 mm Pull spring Configuration: N Blue 1 pc(s)
- TOPJOB®S
- CAGE CLAMP®
Technical specifications
- Product type
Continuity
- Connection
Pull spring
- Configuration
N
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
10 mm²
- AWG (min.)
20
- AWG max.
6
- Clamp width
10 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Factory colour
Blue
- Nominal current
57 A
- Nominal current - rounded value
57 A
- Nominal voltage
800 V
- Min. stripping length
17 mm
- Stripping length (max.)
19 mm
- Manufacturer part #
2010-1304
- Content
1 pc(s)
- Type
2010-1304
- Width
10 mm
- Type
3-Conductor
- Nominal current (details)
57 A (76 A for flexible conductors)
- Connection
-
Documents & Downloads
Datasheet
Datasheet 735554 WAGO 2010-1304 Continuity 10 mm Pull spring Configuration: N Blue 1 pc(s)
User & Safety Instructions
User & Safety Instructions 735554 WAGO 2010-1304 Continuity 10 mm Pull spring Configuration: N Blue 1 pc(s)
Description
The protective conductor terminal 2010 made possible by the CAGE CLAMP S connector simple plug from a wire- and flexible, provided with crimped ferrules, connectors.
