WAGO 2020-107 Grey 25 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Factory colour
Grey
Stripping length (max.)
9 mm
Dim
(L x W x H) 25.2 x 25.19999999 x 40.5 mm
Connection
Spring-loaded terminal
Datasheet (PDF)
Highlights & Details
1-conductor terminal block
- 2020-107
- Industrial packaging, pack of 25
- This text is machine translated.
Technical specifications
- Packaging type
Piece
- Factory colour
Grey
- Stripping length (max.)
9 mm
- Dim
(L x W x H) 25.2 x 25.19999999 x 40.5 mm
- Connection
Spring-loaded terminal
- Weight
16.01 g
- Manufacturer part #
2020-107
- Industrial packaging
Yes
- Content
25 pc(s)
- Material
Thermoplastic
- Series
2020
- Number of pins
7
- Width
25.19999999 mm
- Height
40.5 mm
- Length
25.2 mm
- Series
2020
- Type
2020-107
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (inflexible) (min.)
0.5 mm²
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 654319 WAGO 2020-107 Grey 25 pc(s)
User & Safety Instructions
User & Safety Instructions 654319 WAGO 2020-107 Grey 25 pc(s)
