WAGO 280-640 Shielding terminal 5 mm Pull spring White 100 pc(s)
EAN:
Part number:
Item no:
Product type
Shielding terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Nominal current - rounded value
24 A
Datasheet (PDF)
Number (Package size 100 pc(s))
Total (€ 4.83 / piece)
€ 483.19
plus VAT.
Highlights & Details
3-conductor shield terminal block
- 280-640
Technical specifications
- 3-COND.SCREEN CON.T.B.2,5SQMM F.TS35
- Product type
Shielding terminal
- Connection
Pull spring
- Cross section (flexible) (min.)
0.08 mm²
- Cross section (flexible) (max.)
2.50 mm²
- Cross section (inflexible) (min.)
0.08 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
28
- AWG max.
14
- Clamp width
5 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Factory colour
White
- Nominal current
24 A
- Nominal current - rounded value
24 A
- Min. stripping length
8 mm
- Stripping length (max.)
9 mm
- Manufacturer part #
280-640
- Content
100 pc(s)
- Industrial packaging
Yes
- Type
280-640
- Dim
(W x H) 5 mm x 36.50 mm
- Width
5 mm
- Height
36.50 mm
DIN rail (top hat rail) 35 mm
White
5
50.5 mm
36.5 mm
105-105 °C
V0
TRUE
Spring clamp connection
Spring clamp connection
1
3
0.08-2.5 mm²
0.08-2.5 mm²
0.08-2.5 mm²
Thermoplastic
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 536039 WAGO 280-640 Shielding terminal 5 mm Pull spring White 100 pc(s)
User & Safety Instructions
User & Safety Instructions 536039 WAGO 280-640 Shielding terminal 5 mm Pull spring White 100 pc(s)
Description
White.
