WAGO 280-876 N terminal 5 mm Pull spring Configuration: N Blue 100 pc(s)
EAN:
Part number:
Item no:
Product type
N terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Nominal current - rounded value
16 A
Datasheet (PDF)
Number (Package size 100 pc(s))
Total (€ 3.35 / piece)
€ 335.29
plus VAT.
14-day return policy included
Highlights & Details
2-conductor disconnect/test terminal block
- 280-876
- Industrial packaging with 100 pieces
Technical specifications
- 2-L-TRENN-U.MESSKL.BLAU
- Product type
N terminal
- Features
Complies with ATEX Ex I standards
+ swivelling cutter
+ test option
- Connection
Pull spring
- Configuration
N
- Cross section (flexible) (min.)
0.08 mm²
- Cross section (flexible) (max.)
2.50 mm²
- Cross section (inflexible) (min.)
0.08 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
28
- AWG max.
14
- Clamp width
5 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Blue
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Nominal voltage
400 V
- Min. stripping length
8 mm
- Stripping length (max.)
9 mm
- Manufacturer part #
280-876
- Content
100 pc(s)
- Industrial packaging
Yes
- Type
280-876
- Dim
(W x H) 5 mm x 28.50 mm
- Width
5 mm
- Height
28.50 mm
- Contamination level
3
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 536240 WAGO 280-876 N terminal 5 mm Pull spring Configuration: N Blue 100 pc(s)
User & Safety Instructions
User & Safety Instructions 536240 WAGO 280-876 N terminal 5 mm Pull spring Configuration: N Blue 100 pc(s)
Description
With moving cutting knife, cutting knife holder orange with test hole for test plug Ø 2 mm and Ø 2.3 mm, complies with ATEX Ex i, front wiring, CAGE CLAMP ® connection, horizontal design, with swivelling doors.
