WAGO 282-604 Continuity 8 mm Pull spring Configuration: N Blue 50 pc(s) Package
EAN:
Part number:
Item no:
Packaging type
Package
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
6 mm²
Cross section (inflexible) (max.)
6 mm²
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 2.35 / piece)
€ 117.64
plus VAT.
14-day return policy included
Highlights & Details
2-conductor through terminal block
- 282-604
- Industrial packaging, pack of 50
Technical specifications
- THROUGH TERMINAL BLOCK 6 SQMM BLUE
- Packaging type
Package
- Product type
Continuity
- Features
Complies with ATEX Ex I standards
- Connection
Pull spring
- Configuration
N
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
6 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
24
- AWG max.
10
- Clamp width
8 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Blue
- Nominal current
41 A
- Nominal current - rounded value
41 A
- Nominal voltage
800 V
- Min. stripping length
12 mm
- Stripping length (max.)
13 mm
- Manufacturer part #
282-604
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
282-604
- Dim
(W x H) 8 mm x 31.50 mm
- Width
8 mm
- Height
31.50 mm
- Contamination level
3
- Flammability rating
V0
- Insulation material
Thermoplastic
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 536847 WAGO 282-604 Continuity 8 mm Pull spring Configuration: N Blue 50 pc(s) Package
User & Safety Instructions
User & Safety Instructions 536847 WAGO 282-604 Continuity 8 mm Pull spring Configuration: N Blue 50 pc(s) Package
Description
Complies with ATEX Ex i, blue.
