WAGO 283-101 Continuity 12 mm Pull spring Configuration: L Grey 50 pc(s)
EAN:
Part number:
Item no:
Product type
Continuity
Connection
Pull spring
Cross section (flexible) (max.)
16 mm²
Cross section (inflexible) (max.)
16 mm²
Nominal current - rounded value
76 A
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 3.28 / piece)
€ 163.86
plus VAT.
14-day return policy included
Highlights & Details
2-conductor through terminal block
- 283-101
- Industrial packaging, pack of 50
Technical specifications
- DURCHGANGSKLEMME 16 QMM GRAU
- Product type
Continuity
- Connection
Pull spring
- Configuration
L
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
16 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (inflexible) (max.)
16 mm²
- AWG (min.)
24
- AWG max.
6
- Clamp width
12 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Factory colour
Grey
- Nominal current
76 A
- Nominal current - rounded value
76 A
- Nominal voltage
800 V
- Min. stripping length
16 mm
- Stripping length (max.)
17 mm
- Manufacturer part #
283-101
- Content
50 pc(s)
- Industrial packaging
Yes
- Type
283-101
- Dim
(W x H) 12 mm x 45.50 mm
- Width
12 mm
- Height
45.50 mm
- Contamination level
3
Documents & Downloads
Datasheet
Datasheet 536919 WAGO 283-101 Continuity 12 mm Pull spring Configuration: L Grey 50 pc(s)
User & Safety Instructions
User & Safety Instructions 536919 WAGO 283-101 Continuity 12 mm Pull spring Configuration: L Grey 50 pc(s)
Description
Grey.
