WAGO 753-400 PLC digital input module 753-400 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 34.45 / piece)
€ 34.45
plus VAT.
14-day return policy included
Technical specifications
- 2DI 24V DC 3,0ms
- Product type
PLC digital input module
- Type
753-400
- No. of digital inputs (max.)
2
- Operating voltage
24 V DC
- Height
64 mm
- Length
100 mm
- Width
12 mm
- Max. ambient temperature
+55 °C
- Min. ambient temperature
0 °C
IP20
- Dim
(L x W x H) 100 x 12 x 64 mm
- Manufacturer part #
753-400
- Weight
47.5 g
- Factory colour
Light grey
- Mounting type
DIN rail
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 192128 WAGO 753-400 PLC digital input module 753-400 1 pc(s)
User & Safety Instructions
User & Safety Instructions 192128 WAGO 753-400 PLC digital input module 753-400 1 pc(s)
Description
24 V DC, 30 ms, positive switch, 2 to 4-wire connection, light gray.
