WAGO 870-528/281-581 Dual port PG terminal 5 mm Pull spring Configuration: L Grey 25 pc(s) Package
EAN:
Part number:
Item no:
Packaging type
Package
Product type
Dual port PG terminal
Connection
Pull spring
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
2.50 mm²
Highlights & Details
Two-level terminal block
- 870-528/281-581
- Industrial packaging, pack of 25
- This text is machine translated.
Technical specifications
- Packaging type
Package
- Product type
Dual port PG terminal
- Features
spring-loaded
- Connection
Pull spring
- Configuration
L
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
24
- AWG max.
12
- Clamp width
5 mm
- No. of rows
2
- Pins per row
2
- Number of pins
4
- Factory colour
Grey
- Nominal current
20 A
- Nominal current - rounded value
20 A
- Stripping length (max.)
6 mm
- Manufacturer part #
870-528/281-581
- Content
25 pc(s)
- Industrial packaging
Yes
- Type
870-528/281-581
- Height
40 mm
- Length
10 mm
- Weight
14.637 g
- Connector colour
Grey
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 652061 WAGO 870-528/281-581 Dual port PG terminal 5 mm Pull spring Configuration: L Grey 25 pc(s) Package
